SL-L14 Steel Hook Bending Tester Machine
SL-L14 Steel Hook Bending Tester Machine
SL-L14 Steel Hook Bending Tester Machine
SL-L14 Steel Hook Bending Tester Machine
SL-L14 Steel Hook Bending Tester Machine

SL-L14 Steel Hook Bending Tester Machine

Product Model : SL-L14
Steel hook bending resistance tester has two types, one is electric and another is manual, fix the hook, make the hook at the angle of 180 degree, observe whether the hook break, at the same time, then observe the cracking degree.
Detailed description

Steel Hook Bending Tester Machine


Description

Steel hook bending resistance tester has two types, one is electric and another is manual, fix the hook, make the hook at the angle of 180 degrees, observe whether the hook break, at the same time, then observe the cracking degree.


Application

It is mainly used to test the bending resistance of steel hooks.

The hooks are inserted into the fixture and rotated 180 ° around a column with a diameter of ∮10mm.

The surface is inspected for small cracks and fractures to determine its quality.



Meet the standards

GB 28011, QB / T 1812, QB / T 1813, BS 5131



Specifications
Bending angle: 0 ~ 180 °
Column
: ∮10mm
Dimensions (length × width × height): 20x450x20cm
Weight: about 20kg


What is the Purpose of Bend Testing?

Bend testing a material allows for the determination of that material's ductility,

bend strength, fracture strength, and resistance to fracture.
