Automotive Wires Flammability Testing Equipment
Automotive Wires Flammability Testing Equipment
Automotive Wires Flammability Testing Equipment
Automotive Wires Flammability Testing Equipment
Automotive Wires Flammability Testing Equipment
Automotive Wires Flammability Testing Equipment
Automotive Wires Flammability Testing Equipment

Automotive Wires Flammability Testing Equipment

Product Model : SL-S28
Single wire / cable vertical combustion tester mainly for the conductor diameter greater than 8mm (section area is greater than 0.5mm2) or less than 8mm (section area less than 0.5mm2) of single wire and cable flammability evaluation.
Detailed description

ISO 6722 Automotive Single Wire / Cable Flammability Testing Equipment 60 V/600V



Product introduction

Single wire / cable vertical combustion tester mainly for the conductor diameter greater than 8mm (section area is greater than 0.5mm2) or less than 8mm (section area less than 0.5mm2) of single wire and cable flammability evaluation. Suitable for lighting equipment, low-voltage electrical appliances, household appliances, electrical tools, electric motor, electric tools, electronic instruments, electrical instruments, electrical connectors and accessories such as electrical and electronic products and components of the research, production and quality inspection department. This section adopts the recommended product structure of the air mixing structure in Appendix B of GB18380.12-2008, and also meets the requirements of the quality inspection unit in detail.



Standards

ISO 6722


Application

Rated voltage 60 V MMS or below ground vehicles with low voltage electrical system of primary cable flame retardant test, automotive wires.


Technical parameters

 Dimension  500x650x400 mm
 Burning gas using high purity propane gas  liquefied petroleum gas
 Tested wires length:600mm(24 in)  Sample clamping Angle:45 degree
 The bunsen burner has 13mm inlet hole and 10mm (3/8 in) nominal diameter, spray fire pipe outer flame diameter is 100mm (4in)  inner flame is 50 mm(1/2in),temperature of inner flame as least 900 degree celsius
 The Bunsen burner flame should be put in the bottom of the samples and perpendicular to the axis of the sample  The tip of the inner flame role should be in the midpoint of the sample
 Automatic ignition  flame burn the sample continue 15 seconds and be off automatically
 After burning 15 seconds  will time the continued burning, complete the continued burning time until the continued burning crush out and put off the stop button
 Burning gas is not supplied with the tester  it should be supplied by customer



Product Features

Single cable vertical burning test is set by size Bunsen (Bunsen burner) and the specific gas source (Bing Wan), according to a certain flame height and some application of flame angle on the vertical state of the sample application to test ignition timing, ignition, combustion duration and combustion to assess its length flammable and fire hazard.
